Utility + Commercial · n-type TOPCon · Bifacial dual-glass
RSM132-11-610-635BNDG
Flagship large-format module for solar farms and large commercial arrays — up to 635 W with a 30-year linear power warranty.
- 610–635
- Watts peak
- 23.5%
- Max efficiency
- 15 / 30 yr
- Product / power warranty
- −0.29%/°C
- Temp coefficient (Pmax)
Why this product
- Bifacial dual-glass: up to 10% additional yield from rear-side generation (bifacial factor 80±5%)
- 0.4% annual degradation — 87.4% guaranteed output at year 30
- Excellent anti-LID and anti-PID performance
- Strong weak-light response for early/late and overcast generation
- Positive power tolerance 0~+3% — you never get less than the label
Electrical (STC)
- Rated power (Pmax)
- 610 / 615 / 620 / 625 / 630 / 635 Wp
- Module efficiency
- 22.6 – 23.5%
- Open-circuit voltage (Voc)
- 48.69 – 49.65 V
- Short-circuit current (Isc)
- 15.92 – 16.22 A
- Power tolerance
- 0 ~ +3%
- Bifacial factor
- 80 ± 5%
- Equivalent power with 10% rear gain
- 671 – 699 Wp
Mechanical
- Cell technology
- n-type TOPCon, 132 cells (6×11 + 6×11)
- Dimensions
- 2382 × 1134 × 30 mm
- Weight
- 32.5 kg
- Glass
- 2.0 mm AR-coated heat-strengthened front · 2.0 mm rear
- Frame
- Anodized aluminium alloy, silver
- Junction box
- Potted, IP68, 3 bypass diodes
- Connector
- PV-SY02 / others
- Max mechanical load
- 5400 Pa front / 2400 Pa back
Temperature & ratings
- Temperature coefficient (Pmax)
- −0.29%/°C
- Temperature coefficient (Voc)
- −0.25%/°C
- Operational temperature
- −40°C ~ +85°C
- Max system voltage
- 1500 VDC
- Max series fuse rating
- 35 A
- NMOT
- 44°C ± 2°C
Warranty
- Product warranty
- 15 years
- Performance warranty
- 30 years linear · 0.4% annual degradation
- Guaranteed output, year 30
- 87.4%
Specifications from official Risen documentation. Always confirm against the current datasheet before specifying.
n-type TOPCon
More yield, lower cost per watt.
High Power Generation Yield
Excellent temperature coefficient (−0.29%/°C), a high bifacial factor (80 ± 5%, up to ~10% rear gain) and strong low-light performance.
High Packing Capacity & Low Transportation Costs
Fully utilises each container's internal volume — more power loaded per container, and a lower transport cost per watt.
Optimal Compatibility with Tracking Brackets
At the same installed capacity it fits more modules on a single tracker than equivalent PERC products — fewer trackers, and lower bracket cost across the project.
Low BOS Costs
Higher string power than equivalent PERC modules in the same conditions cuts per-watt spend on brackets, pile foundations, cabling and installation.
