Utility · eTron Series · Liquid-cooled BESS · LFP
SU5016E2500KC
The eTron 5 MWh liquid-cooled ESS — 5 MWh of LFP capacity and 2.5 MW of power in a single 20-foot unit, IEC-certified for 50 Hz grids.
- 5,016
- kWh nameplate capacity
- 2.5 MW
- Nominal AC power
- LFP
- Liquid-cooled battery
- IP55
- −30°C ~ +55°C rated
Why this product
- Five-layer protection architecture with BMS, PCS and EMS integrated seamlessly
- Intelligent liquid cooling keeps cells in their optimal temperature band for life and safety
- Safe LFP chemistry: 314 Ah cells in a 416S12P configuration
- Multi-layer fire safety: dry pipe, gas detection and ventilation, aerosol suppression and alarms
- Modular plug-and-play deployment in a standard 20-ft container — mirrored -L/-R configurations available
- IEC-certified for 50 Hz grids including Australia (IEC 62477-1, 62619, 63056, 62933 and more)
System
- Nominal AC power
- 2,500 kW
- Nameplate capacity
- 5,015.96 kWh
- Communication
- Modbus TCP/IP
- Auxiliary power supply
- AC 400 V / 3P4L 50 Hz
Battery
- Chemistry
- LFP (lithium iron phosphate)
- Cell capacity
- 314 Ah
- Configuration
- 416S12P
- Nominal voltage
- 1,331.2 V
- Voltage range
- 1,123.2 – 1,497.6 V
Environment & protection
- Degree of protection
- IP55
- Operating temperature
- −30°C ~ +55°C (derating above 50°C)
- Relative humidity
- 0 – 95% RH
- Max working altitude
- 4,000 m
- Noise emission
- ≤ 80 dB @ 1 m
General
- Dimensions (W×H×D)
- 6,058 × 2,896 × 2,438 mm (20-ft container)
- Weight
- 40.3 ± 0.5 t
- Cooling
- Intelligent liquid-cooled
- Fire suppression
- Dry pipe · gas detection & ventilation · aerosol · alarm system
- Certificates
- IEC 62477-1 · IEC 62619 · IEC 63056 · IEC 60730 · IEC 61000-6-2/-6-4 · IEC 62933
Specifications from official Risen documentation. Always confirm against the current datasheet before specifying.
